Specification

1. Electrical Properties:

1.1 Frequency Range …………………………2.4GHz~2.5GHz
1.2 Impedance……………………………………50Ω Nominal
1.3 VSWR…………………………………………2.0 Max.
1.4 Return Loss…………………………………-9.54dB Max.
1.5 Electrical Wave………………………………1/2λ Diople
1.6 Gain……………………………………………3.0dBi
1.7 Admitted Power………………………………1 W
1.8 Polarization……………………………………Linear

2. Physical Properties:

2.1 Cable…………………………………………φ1.13Cable 50Ω
2.2 Antenna Sleeve……… ………………………TPE
2.3 Antenna Base…………………………………PC
2.4 Operating Temp………………………………-20℃~+65℃
2.5 Storage Temp…………………………………-30℃~+75℃
2.6 Color……………………………………………Shapphire Blue
2.7 Conncctor………………………………………I-PEX
